工作室尺寸(mm)

Work room size

460×460×480

680×680×650

780×780×850

外形尺寸(mm)

Boundary dimension

2000×1100×1650

2350×1360×2000

2500×1580×2200

技術參數

溫度范圍perature arrange

高溫 High

+60℃~200℃

低溫 low

-75℃~-10℃

溫度預熱上限/預冷下限Precooling/preheating temperature

+200℃/-75℃

溫度偏差Temperature deviation

±2.0℃

升溫時間/降溫時間Heating/cooling time

About:40min(RT~200℃)/40min(RT~-75℃)

溫度恢復時間Temperture recovery

≤5分鐘min

提籃稱重

10Kg

18Kg

25Kg

制冷系統

制冷機組/方式

進口德國谷輪或發過泰康半封閉壓縮機/二元復疊壓縮制冷 Imported German or French Tecumseh Copeland semi-hermetic compressor/dual cascade compression refrigeration

冷卻方式Cooling method

水冷Water cooling(冷卻水水壓cooling water pressure:0.2~0.4Mpa,水溫water temperature: ≤30℃)

冷凝器 Condenser

 不銹鋼釬焊板式換熱器 Stainless steel welded plate heat exchanger

加熱器/蒸發器 Heater/evaporimeter

鎳洛合金電加熱器/翅片式蒸發器 Nichrome electric heater/finned evaporator

循環風機 circulating fan

軸流風機 Axial air machine

氣動氣缸 Cylinder

提籃在高、低溫室轉換去東區 High&low temperature transfrom actuator

空氣壓縮機 Air compressor

提供驅動氣缸的壓縮空去（選配件）  Compressed air of supply drive cylinder

安全保護措施 Protection

超溫、過載、超壓、漏電、短路、電源缺相、錯相保護 Over temperature,over load,over pressure,leakage,cutting-out,power open phase,angular misalignment and protection

材料

機箱外殼 Outer materials

SUS304不銹鋼板或優質冷軋鋼板靜電噴塑 SUS304# stainless steel treated with mist

機箱內壁Inner material

SUS304 不銹鋼板 Inner box is stainless steel

保溫材料 Insulation materials

硬質聚氨酯泡沫及超細玻璃棉 Heat-resistance high-density aluminum silicate fiber cotton or foam insulator materials

標準配置 Accessories

測試孔、照明燈、雙層真空防彈玻璃觀察窗 Test port hole,light,viewing window

電源 Power

380V±10%,50hz,3P+N-G
